Designing AI-Enhanced Robotic Systems: A Smart Traffic Controller

1Seventeen cars and one green light

At a busy crossroads in the morning, seventeen cars queue on the road from a residential area while two wait on the cross street. A traditional traffic light gives each road the same 30 seconds of green, every cycle, whatever is happening. The long queue grows; the cross street's green runs empty. A traffic police officer would watch the queues and change the lights to suit them, but cannot stand at every junction all day. A smart traffic controller does that job with cameras or road sensors and a decision rule: it is a robot whose actuators are the lights themselves. This lesson uses it to practise designing an AI-enhanced robotic system from first principles.

2A design canvas for an AI-enhanced robot

Before building, answer every row. The right-hand column is the smart traffic controller.

3Simulate before you build

You cannot experiment with real traffic, but you can with a simulation. The program below models one hour at a junction, second by second: cars arrive at random (at rates labelled illustrative), one car leaves every 2 seconds from the road with the green, and switching the lights costs 4 seconds of amber and all-red. It compares three controllers on exactly the same random arrivals: an equal fixed split, a fixed split tuned to the morning traffic, and a smart controller that senses the queues. It also runs a second hour in which the busy road changes half-way through, as happens when morning traffic gives way to traffic leaving the city centre. It was run with python3.

import random

def rates(t, flip):
    """Cars arriving per second (illustrative). With flip, the busy road changes after 30 min."""
    busy_ns = not (flip and t >= 1800)
    return {"NS": 0.30, "EW": 0.10} if busy_ns else {"NS": 0.10, "EW": 0.30}
SWITCH_TIME = 4                      # seconds of amber and all-red between greens

def other(d):
    return "EW" if d == "NS" else "NS"

def fixed_time(green, t_green, queues):
    return t_green >= 30             # always 30 s of green, whatever the queues

def fixed_tuned(green, t_green, queues):
    return t_green >= (45 if green == "NS" else 15)   # split chosen for this demand

def smart(green, t_green, queues):
    """Sense the queues: keep green while cars are flowing, up to 50 s;
    switch when this road is empty and cars wait on the other road."""
    if t_green < 10:                 # minimum green, for pedestrians and safety
        return False
    if not queues[other(green)]:     # nobody waiting on the other road
        return False
    return not queues[green] or t_green >= 50

def simulate(controller, flip=False, seconds=3600, seed=7):
    rng = random.Random(seed)        # same arrivals for every controller
    queues = {"NS": [], "EW": []}    # arrival time of each waiting car
    green, t_green, switching = "NS", 0, 0
    waits = []
    for t in range(seconds):
        for road, rate in rates(t, flip).items():
            if rng.random() < rate:
                queues[road].append(t)
        if switching:                # lights changing: nobody moves
            switching -= 1
            if switching == 0:
                green, t_green = other(green), 0
            continue
        if t_green % 2 == 0 and queues[green]:       # one car leaves every 2 s
            waits.append(t - queues[green].pop(0))
        t_green += 1
        if controller(green, t_green, queues):
            switching = SWITCH_TIME
    still_waiting = [seconds - a for q in queues.values() for a in q]
    all_waits = waits + still_waiting
    return sum(all_waits) / len(all_waits), len(waits), len(still_waiting)

for flip in (False, True):
    print("Busy road changes after 30 min" if flip else "Same demand all hour")
    for name, ctrl in (("fixed 30-30", fixed_time), ("fixed 45-15", fixed_tuned), ("smart", smart)):
        mean, passed, left = simulate(ctrl, flip)
        print(f"  {name:11}  mean wait {mean:6.1f} s   cars through {passed}   still queuing {left}")

Output:

Same demand all hour
  fixed 30-30  mean wait  429.9 s   cars through 1124   still queuing 310
  fixed 45-15  mean wait   20.0 s   cars through 1431   still queuing 3
  smart        mean wait   14.8 s   cars through 1430   still queuing 4
Busy road changes after 30 min
  fixed 30-30  mean wait  302.4 s   cars through 1311   still queuing 159
  fixed 45-15  mean wait  227.0 s   cars through 1131   still queuing 339
  smart        mean wait   15.2 s   cars through 1465   still queuing 5

4Making the controller smarter

• Fuzzy logic (unit 3): inputs "queue on green road" and "queue on red road" with terms short, medium and long, and an output "green extension" from short to long, give smooth timing instead of sudden thresholds.
• Coordination: neighbouring junctions share their timings so that cars meet a "green wave".
• Learning: a controller can learn timings from months of counts, or by reinforcement learning in simulation (lesson 4) before being trusted on the street.
• Priority: ambulances and buses can request green as they approach.

5Hands-on: tune and test the junction

1. Run traffic.py. Then change the arrival rates to describe a quieter evening (for example 0.15 and 0.12) and run it again. Which controller wins now, and by how much?
2. In smart, change the minimum green from 10 s to 20 s and the maximum from 50 s to 30 s. Record the effect on the mean wait in both scenarios.
3. Add a pedestrian rule: every third cycle, a 12-second all-red for pedestrians. How much does it cost drivers?
4. Complete the design canvas for a different AI-enhanced robot: for example a school-gate robot that checks uniforms, or a drone that counts cattle. Include at least two safety requirements and one privacy requirement.

Check: you can explain each change in the results by referring to capacity or to what the controller senses.
